Recording
Video compression : H.265 Pro+/H.265 Pro/H.265/H.264+/H.264
Encoding resolution :
When 1080p Lite mode is not enabled :
4 MP lite/3 MP/1080p/720p/VGA/WD1/4CIF/CIF;
When 1080p Lite mode is enabled :
4 MP lite/3 MP/1080p lite/720p lite/VGA/WD1/4CIF/CIF
Frame rate :
Main stream :
When 1080p Lite mode is not enabled:
For 4 MP stream access: 4 MP lite@15fps; 1080p lite/720p/WD1/4CIF/VGA/CIF@25fps (P)/30fps (N)
For 3 MP stream access: 3 MP/1080p/720p/VGA/WD1/4CIF/CIF@15fps
For 1080p stream access: 1080p/720p@15fps; VGA/WD1/4CIF/CIF@25fps (P)/30fps (N)
For 720p stream access: 720p/VGA/WD1/4CIF/CIF@25fps (P)/30fps (N)
When 1080p Lite mode enabled:
4 MP lite/3 MP@15fps; 1080p lite/720p lite/VGA/WD1/4CIF/CIF@25fps (P)/ 30fps (N)
Sub-stream:
WD1/4CIF@12fps; CIF@25fps (P)/30fps (N)
Video bit rate : 32 Kbps to 6 Mbps
Dual stream : Support
Stream type : Video, Video & Audio
Audio compression : G.711u
Audio bit rate : 64 Kbps

Video and Audio
IP video input : 8-ch (up to 24-ch)
Up to 6 MP resolution
Support H.265+/H.265/H.264+/H.264 IP cameras
Analog video input : 16-ch
BNC interface (1.0 Vp-p, 75 ?), supporting coaxitron connection
HDTVI input : 4 MP, 3 MP, 1080p30, 1080p25, 720p60, 720p50, 720p30, 720p25
AHD input : 4 MP, 1080p25, 1080p30, 720p25, 720p30
HDCVI input : 1080p25, 1080p30, 720p25, 720p30
CVBS input : PAL/NTSC
CVBS output : 1-ch, BNC (1.0 Vp-p, 75 ?), resolution: PAL: 704 × 576, NTSC: 704 × 480
VGA/HDMI output :
VGA: 1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
HDMI: 1-ch, 4K (3840 × 2160)/30Hz, 2K (2560 × 1440)/60Hz, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
Audio input : 4-ch, RCA (2.0 Vp-p, 1 K?)
Audio output : 2-ch, RCA (Linear, 1 K?)
Two-way audio : 1-ch, RCA (2.0 Vp-p, 1 K?) (independent)
Synchronous playback : 16-ch

Network
Remote connections : 128
Network protocols : TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP™, HTTPS, ONVIF, SNMP
Network interface : 1, RJ45 10M/100M/1000M self-adaptive Ethernet interface

Auxiliary interface
SATA : 4 SATA interfaces
eSATA : Support
Capacity : Up to 10 TB capacity for each disk
Serial interface : RS-232, RS-485 (full-duplex), Keyboard
USB interface :
Front panel : 2 × USB 2.0
Rear panel : 1 × USB 3.0
Alarm in/out : 16/4

General
Power supply : 100 to 240 VAC
Consumption (without HDD) : 55 W
Working temperature : -10 °C to +55 °C (+14 °F to +131 °F)
Working humidity : 10% to 90%
Dimensions (W × D × H) : 445 × 390 × 70 mm (17.5 × 15.4 × 2.8 inch)
Weights (without HDD) : 5 kg (11.0 lb)
