Products Infomation

NETWORK
Technology : GSM / CDMA / HSPA / EVDO / LTE
2G bands : GSM 850 / 900 / 1800 / 1900 - SIM 1 & SIM 2 (dual-SIM model only)
CDMA 800 / 1900
3G bands : HSDPA 850 / 900 / 1700(AWS) / 1900 / 2100
CDMA2000 1xEV-DO
4G bands : 1, 2, 3, 4, 5, 7, 8, 12, 13, 17, 18, 19, 20, 25, 26, 28, 32, 38, 39, 40, 41, 66
Speed : HSPA 42.2/5.76 Mbps, LTE-A (7CA) Cat20 2000/200 Mbps

Build : Glass front (Gorilla Glass Victus), glass back (Gorilla Glass Victus), stainless steel frame
SIM : Single SIM (Nano-SIM and/or eSIM) or Hybrid Dual SIM (Nano-SIM, dual stand-by)
Samsung Pay (Visa, MasterCard certified)
IP68 dust/water resistant (up to 1.5m for 30 mins)
Stylus, 9ms latency (Bluetooth integration, accelerometer, gyro)

DISPLAY
Type : Dynamic AMOLED 2X, 120Hz, HDR10+
Size : 6.9 inches, 116.7 cm2 (~91.7% screen-to-body ratio)
Resolution : 1440 x 3088 pixels (~496 ppi density)
Protection : Corning Gorilla Glass Victus
Always-on display
120Hz@FHD/60Hz@QHD refresh rate

PLATFORM
OS : Android 10, One UI 2.5
Chipset : Exynos 990 (7 nm+) - Global
Qualcomm : SM8250 Snapdragon 865+ (7 nm+) - USA
CPU : Octa-core (2x2.73 GHz Mongoose M5 & 2x2.50 GHz Cortex-A76 & 4x2.0 GHz Cortex-A55) - Global
Octa-core : (1x3.0 GHz Kryo 585 & 3x2.42 GHz Kryo 585 & 4x1.8 GHz Kryo 585) - USA
GPU : Mali-G77 MP11 - Global
Adreno : 650 - USA

MEMORY
Card slot : microSDXC (uses shared SIM slot)
Internal : 256GB 8GB RAM, 512GB 8GB RAM
UFS 3.0

MAIN CAMERA
Triple : 108 MP, f/1.8, 26mm (wide), 1/1.33", 0.8µm, PDAF, Laser AF, OIS
12 MP, f/3.0, 120mm (periscope telephoto), 1.0µm, PDAF, OIS, 5x optical zoom, 50x hybrid zoom
12 MP, f/2.2, 120?, 13mm (ultrawide), 1/2.55", 1.4µm
Features : LED flash, auto-HDR, panorama
Video : 8K@24fps, 4K@30/60fps, 1080p@30/60/240fps, 720p@960fps, HDR10+, stereo sound rec., gyro-EIS & OIS

SELFIE CAMERA
Single : 10 MP, f/2.2, 26mm (wide), 1/3.2", 1.22µm, Dual Pixel PDAF
Features : Dual video call, Auto-HDR
Video : 4K@30/60fps, 1080p@30fps

SOUND
Loudspeaker : Yes, with stereo speakers
3.5mm jack : No
32-bit/384kHz audio
Tuned by AKG

COMMS
WLAN : Wi-Fi 802.11 a/b/g/n/ac/6, dual-band, Wi-Fi Direct, hotspot
Bluetooth : 5.0, A2DP, LE, aptX
GPS : Yes, with A-GPS, GLONASS, BDS, GALILEO
NFC : Yes
Radio : FM radio (Snapdragon model only; market/operator dependent)
USB : USB Type-C 3.2, USB On-The-Go

FEATURES
Sensors : Fingerprint (under display, ultrasonic), accelerometer, gyro, proximity, compass, barometer
Samsung Wireless DeX (desktop experience support)
ANT+
Bixby natural language commands and dictation

BATTERY
Type : Li-Ion 4500 mAh, non-removable
Charging : Fast charging 25W
USB : Power Delivery 3.0
Fast Qi/PMA wireless charging 15W
Reverse wireless charging 4.5W
