Products Infomation

Camera
Image Sensor : 2 MP CMOS
Signal System : PAL/NTSC
Resolution : 1920 (H) × 1080 (V)
Frame Rate :
TVI : 1080P@30fps, 1080P@25fps
CVI : 1080P@30fps, 1080P@25fps
AHD : 1080P@30fps, 1080P@25fps
CVBS : PAL/NTSC
Min. illumination : 0.0005 Lux@(F1.0, AGC ON), 0 Lux with white light ON
Shutter Time :
PAL : 1/25 s to 1/50, 000 s
NTSC : 1/30 s to 1/50, 000 s
Slow Shutter : Max. 16 times
Lens : 2.8 mm, 3.6 mm, 6 mm fixed lens
Field of View :
2.8 mm, horizontal FOV: 98°, vertical FOV: 52°, diagonal FOV: 116°
3.6 mm, horizontal FOV: 77°, vertical FOV: 42°, diagonal FOV: 91°
6 mm, horizontal FOV: 51°, vertical FOV: 28°, diagonal FOV: 59°
Lens Mount : M12
Light Alarm : Solid Light Alarm (White Light)
Day & Night : 24/7 Color Imaging
WDR (Wide Dynamic Range) : 130dB
Angle Adjustment : Pan: 0 to 360°, Tilt: 0 to 75°, Rotation 0 to 360°

Menu
White Light : Auto/Off
Image Mode : STD/HIGH-SAT/HIGHLIGHT
AGC : Yes
Day/Night Mode : Color
White Balance : Auto/Manual
AE (Auto Exposure) Mode : WDR/BLC/HLC/Global/HLS
Privacy Mask : 4 programmable privacy masks
Motion Detection : 4 programmable motion areas
Noise Reduction : 3D DNR/2D DNR
Language : English
Function : Defective Pixel Correction;Sharpness;Mirror;Contrast;Brightness;Anti-Banding;Smart Light
Lighting Mode : White Light

Interface
Video Output : Switchable TVI/AHD/CVI/CVBS

General
Operation Conditions : -40 °C to 60 °C (-40 °F to 140 °F), humidity 90% or less (non-condensing)
Power Supply : 12 VDC ± 25%
Power Consumption : Max. 4.2 W
Protection Level : IP67
Material : Main body: Metal, Enclosure: Plastic
IR Range : Up to 40 m
Communication : HIKVISION-C
Dimensions : ? 109.98 mm × 98.27 mm (? 4.33" × 3.87")
Weight : Approx. 348.5 g (0.77 lb.)
