Products Infomation

Camera
Image Sensor : 2 MP CMOS
Max. Resolution :1920 (H) × 1080 (V)
Min. Illumination : 0.0005 Lux @ (F1.0, AGC ON), 0 Lux with white light
Shutter Time :
PAL : 1/25 s to 1/50, 000 s
NTSC : 1/30 s to 1/50, 000 s
Day & Night : Color
Angle Adjustment :Pan: 0 to 360°, Tilt: 0 to 75°, Rotation: 0 to 360°
Signal System : PAL/NTSC

Lens
Lens Type : 3.6 mm, 6 mm fixed lens
Focal Length & FOV :
3.6 mm : horizontal FOV: 83.0°, vertical FOV: 44.4°, diagonal FOV: 98.0°
6 mm : horizontal FOV: 51.0°, vertical FOV: 28.5°, diagonal FOV: 58.7°
Lens Mount : M16

Illuminator
Supplement Light Range : Up to 20 m

Image Parameters Switch : STD/HIGH-SAT
Image Settings : Brightness, Sharpness, Mirror, Smart Light, Defective Pixel Correction
Frame Rate :
TVI: 1080p@30fps, 1080p@25fps
AHD: 1080p@30fps, 1080p@30fps
CVI: 1080p@30fps, 1080p@25fps
CVBS: PAL/NTSC
Wide Dynamic Range (WDR) : 130 dB
Image Enhancement : BLC, HLC
White Balance : ATW/MANUAL
White Light : AUTO/OFF
AGC : Support

Interface
Video Output : Switchable TVI/AHD/CVI/CVBS

General
Material :
Enclosure: Plastic
Main Body: Metal
Dimension : 109.82 mm × 93.66 mm (4.32" × 3.7")
Weight : Approx. 390 g ( 0.86 lb.)
Operating Condition : -40° C to 60° C (-40° F to 140° F), Humidity 90% or less (no condensation)
Communication : HIKVISION-C
Language : English
Power Supply : 12 VDC ± 25%
Consumption : Max. 6.6 W
Protection : IP67
